Description
Implementation of a button for an external power switch to power Kobra X printer on and off
Motivation
Many KobraX printers are likely controlled remotely because the printer is not located right next to the workstation (e.g., in a separate workshop in the house).
To switch the printer on and off, switches controlled via HTTP requests are typically used, such as Sonoff/Tasmota switches.
Proposed Implementation
Therefore, it would be useful to implement an On/Off button, for example in the "Printers" dialog as shown in the attached image.
The URLs for powering on (e.g., http://192.168.1.235/cm?cmnd=Power%20on) and powering off (http://192.168.1.235/cm?cmnd=Power%20off) could be configured in Settings.
Thanks for the suggestion, @ok24 — this is a real gap for anyone running the printer on a smart plug in a separate room, since the printer itself has no MQTT command to power off or enter standby (nothing like that exists in its protocol — only heaters/motors/etc. can be controlled remotely, the mains power itself can't).
A Tasmota-style smart plug is the right way to solve this, and I'd rather implement it as Moonraker's standard
machine.device_powerAPI than as a bridge-specific button: Mainsail and Fluidd already have a built-in "Power Devices" panel that renders on/off toggles automatically for anything reported there — no custom UI needed on either side, and it's the same mechanism people already use for other Klipper-connected smart plugs (Tasmota, generic HTTP, Home Assistant, etc.), not just this bridge. Currentlymachine.device_power.*isn't implemented at all, so nothing shows up there yet.I'll add it as a config entry (device name + on/off URL, e.g. your Tasmota
cmnd=Power%20on/offexample) so a configured switch appears the same way a native Moonraker power device would in Mainsail/Fluidd — should also cover other HTTP-controllable switches, not just Tasmota specifically.Picking this up as a real feature — will follow up here once there's something to test.
Implemented, @ok24 — went with a bridge-native button as you suggested rather than routing through Moonraker.
Added a "Power Switch" section in Settings where you can configure
power_on_url,power_off_url, and an optionalpower_status_url(your Tasmota example works directly:http://192.168.x.x/cm?cmnd=Power%20on/...Power%20off, and...cmnd=Powerfor status). Once at least one URL is set, a 🔌 button appears on that printer's card in the Printers grid — clicking it fires a plain HTTP GET at the configured URL, no Moonraker/Mainsail dependency at all. If a status URL is configured, the button also shows the plug's current on/off state (parses Tasmota's{"POWER":"ON/OFF"}response, with a plain-text fallback for other switch firmwares) instead of a static icon.One safety detail: turning power off asks for confirmation first, since there's no way for the bridge to know a print is running on a smart plug it doesn't otherwise talk to.
Also worth mentioning since it surfaced while testing this: found and fixed a bug where
config.inivalues containing a%character (exactly what your Tasmota URL example has,Power%20on) were rejected outright when saving settings — configparser's default string interpolation misread it as a broken variable reference. Would have affected anyone trying to save a URL like yours regardless of this feature.Committed on
nightlywith test coverage, going out with the next nightly build.great news ! - I will test it at soon it is available. Thank you very much !
I testet the new feature today evening. The tasmota switch operates very well with the new settings.
In my opinion only the visualization has a little problem. As shown in the screenshot the power state is "off" (the popup hint for the next click on the button shows "Power:on"). But the green circle and text didn't have this state and shows "ready" with green color.
