Control your Anycubic Kobra X with OrcaSlicer — no Klipper, no Raspberry Pi.
KX-Bridge is a Moonraker-compatible bridge that communicates directly with the printer.

Quick Start in 3 Steps

Step 1 – Prepare the printer

Enable LAN mode on the Kobra X:
Printer display → Settings → Enable LAN mode

Step 2 – Get credentials

The MQTT credentials are printer-specific. Here's how to get them:

Open AnycubicSlicerNext and connect the printer (wait until status is shown)
Run extract_credentials.exe (Windows) or extract_credentials (Linux) — outputs Username, Password, Device ID and printer IP
Note / copy the values

Download: gitea.it-drui.de/viewit/KX-Bridge-Release/releases → extract_credentials.exe (Windows) / extract_credentials (Linux) in the release assets

Step 3 – Start the bridge

./start.sh

The script builds the Docker image automatically on first run.

Open Web-UI: http://BRIDGE-IP:7125
→ The ⚙ menu opens automatically on first start
→ Enter credentials from Step 2 → Save & Restart

Connect OrcaSlicer:
Printer → Connection type Moonraker → Host: http://BRIDGE-IP:7125

Important: Connection type must be Moonraker (not "Bambu" or "Klipper").
Enter the full URL including http:// and port :7125 in the host field.

⚠️ Upgrading from 0.9.1 or earlier

Starting with 0.9.2, KX-Bridge stores settings in config/config.ini instead of .env.

Migration is automatic — no manual action required:

On first start after upgrade, the bridge reads your existing .env and creates config/config.ini automatically
Settings now survive docker-compose restart and future updates
The .env file stays mounted read-only as a migration source — you can keep it in place
If you want to create a config.ini manually: copy config/config.ini.example

What's supported?

Feature	Details
Printer status	Temperature, progress, state, remaining time
Print control	Start, pause, resume, cancel
Temperature control	Nozzle and bed during print
Print speed	Silent / Normal / Sport
AMS filament change	Load / unload filament
Light & fan	Print light and fan speed
Web-UI	Dashboard, motion control, camera view
Self-update	Install new versions directly in the browser
OrcaSlicer	Moonraker protocol (HTTP + WebSocket)

Alternatives to Docker

Linux binary (no Docker needed):

chmod +x kx-bridge
./kx-bridge

Python directly:

pip install aiohttp
python bridge/kobrax_moonraker_bridge.py

Web-UI available at http://localhost:7125 — the ⚙ menu guides through initial setup.

Useful commands

# Show logs
docker-compose logs -f

# Stop bridge
docker-compose down

# Restart bridge (after update)
./start.sh

Troubleshooting

"Wrong MQTT credentials" on start:

Restart AnycubicSlicerNext, reconnect the printer, run extract_credentials again
Enter only the IP address, no port (✗ 192.168.1.102:9883 → ✓ 192.168.1.102)

Printer not found / no LAN mode:

On the printer display: Settings → Enable LAN mode
Printer and bridge must be on the same network

Docker: Permission denied:

sudo usermod -aG docker $USER  # then log out and back in

Security

The bridge is accessible on the local network at http://<host-IP>:7125 — do not expose to the internet
config/config.ini contains printer credentials — do not share publicly
Credentials do not grant access to Anycubic cloud services

License

Interoperability research under §69e UrhG — private, non-commercial use only.
